ZG-4 Automatic Sausage Knotting Machine

ZG-4 Automatic Sausage Knotting Machine
  • ZG-4 Automatic Sausage Knotting Machine
  • Product details
Model No.︰ZG-4
Brand Name︰FENGXIANG
Country of Origin︰China
Unit Price︰-
Minimum Order︰1 pc
Share on:

 Total 11 Related Items
Prev7891011Next

Product Description



Model:ZG-4

Product Discription:

Meat processing companies often have to make strategies constantly to reduce the loss of casings. And the workers are often not very passionate because of the boredom they find in work .Maybe such problems are not caused by management, but by the wrong choice of machines.

With a careful design, exquisite production and the price advantage, our new machine FXZG-1,the four-line fully-automatic sausage tying machine develop in 2009, can be the most sophisticated equipment for all meat processing companies.

Compared with FXZG-1,FXZG-4 has the following advantages:

* It can operate in a higher speed of 240-360 links per minute, which helps to increase the efficiency by 30%.

* It can be more easily washed and maintained. A sink is added to the wring and necking parts. And below the conveyor belt there is a drawer-like device for the waste.

* It needs less air and lower air pressure. It can operate under the pressure of 0.3Mpa. The aerodynamic components we use in this machine are all produced by the Japanese components we use in this machine are all produced by the Japanese company SMC. So this machine can operate in a more steadily and light way, and the tying length will not be affected by the air pressure source.



Main Parameters:

Capacity Sausage Diameter Sausage Length Range Working Air Pressure
about 13000pc/h 9-30mm 20-400mm 0.4-0.6MPa
Price Terms︰FOB Guangzhou or Shenzhen(or named by client)
Payment Terms︰TT/LC or Cash
Packing︰By stander exporting plywood case, well protected while transporting.
Product Image
